Electro Galvanized Steel Sheet

Electro-galvanized steel is a plating process where the steel is placed in an electrically charged solution of zinc and saline. This causes the zinc to chemically bond to the conductive steel. Electro-plating is frequently used for coiled sheet steel, which is later formed into shapes such as c-purloins, and corrugated sheets or can be formed and welded into pipes and tubes.

Classification :

Keywords: Steel Plate

+8618306409158

sales02@yehuimetal.com

E-mail

RELATED PRODUCTS

ONLINE MESSAGE

PRODUCT DETAILS

Electro galvanized steel sheets are steel sheets that have been electroplated with a protective layer of zinc. An electric current is used to apply a thin layer of zinc to the surface of the steel sheet during this process. The electroplating process provides a uniform coating thickness across the entire surface of the steel sheet.

Product Name	Galvanized Sheet
Thickness	0.12mm-6.00mm
Width	600mm-1500mm
Length	1m-12m, support customization
Standard	AISI,ASTM,DIN,JIS,GB,JIS,SUS,ENWait
Zinc layer	Hot Galvanizing:60-275g/m²
Zinc layer	Pre-galvanized:80-275g/m²

Chemical composition

Standard	Grade	C	Si	Mn	P	S	Ti
Forcold forming Chinese Standard	DX51D Z	0.12	0.50	0.60	0.100	0.045	0.30
	DX52D With	0.12	0.50	0.60	0.100	0.045	0.30
	DX53D Z	0.12	0.50	0.60	0.100	0.045	0.30
	DX54D Z	0.12	0.50	0.60	0.100	0.045	0.30
	DX56D Z	0.12	0.50	0.60	0.100	0.045	0.30
	DX57D Z	0.12	0.50	0.60	0.100	0.045	0.30
Forcold forming Japanese Standard	SGCC	0.15	0.50	0.80	0.050	0.030	0.025
	SGCD1 SGCD2	0.12 0.10	0.50 0.50	0.60 0.45	0.040 0.030	0.030 0.030	0.025 0.025
	SGCD3	0.08	0.50	0.45	0.030	0.030	0.025
	SGCD4	0.06	0.50	0.45	0.030	0.030	0.025
ForStructure Japanese Standard	SGC340	0.25	0.50	1.70	0.200	0.035	0.025
	SGC400 SGC440	0.25 0.25	0.50 0.50	1.70 2.00	0.200 0.200	0.035 0.035	0.150 0.150
	SGC490	0.30	0.50	2.00	0.200	0.035	0.025
	SGC510	0.30	0.50	2.50	0.200	0.035	0.025
ForStructure AISI Standard	S220GD Z	0.20	0.60	0.70	0.100	0.045	0.025
	S250GD With	0.20	0.60	0.70	0.100	0.045	0.025
	S280GD Z	0.20	0.60	0.70	0.100	0.045	0.025
	S320GD Z	0.20	0.60	0.70	0.100	0.045	0.025
	S350GD Z	0.20	0.60	0.70	0.100	0.045	0.150
	S550GD Z	0.20	0.60	0.70	0.100	0.045	0.150

Mechanical properties

Grade	Yield strength MPa≥	Tensile Strength MPa≥	Elongation A%≥
DX51D Z/ZM/AZ/AM	240-380	270-500	22
DX52D Z/ZM/AZ/AM	140-300	270-420	26
DX53D Z/ZM/AZ/AM	140-260	270-380	30
DX54D Z/ZM/AZ/AM	120-220	260-350	36
S220GD Z/ZM/AM	220	300	20
S250GD Z/ZM/AZ/AM	250	330	19
S280GD Z/ZM/AM	280	360	18
S300GD A/AM	300	380	18
S320GD Z/ZM/AM	320	390	17
S350GD Z/ZM/AZ/AM	350	420	16
S450GD A/AM	450	480	15
S550GD Z/ZM/AZ/AM	550	550	-

Galvanized Surface Selection

Zero Spangle	Minimized Spangle	Normal Spangle	Large Spangle

Warehouse Storage

Hebei Yehui Metal Materials Co., Ltd. as a leader manufacturer in steel supplier from China, is a reliable and integrity steel supplier. With more than 10 years steel processing and exporter experiences, we have a factory building of 20000 square meters and annual production of 23,000 tons. We specialized in the production of stainless steel, carbon steel, galvanized steel, aluminum, copper products, etc., suitable for fields such as engineering, coal mining, textiles, electricity, boilers, machinery, etc. Our products have passed the ISO9001 quality system certification and the EU CE certification.

Packing And Shipping

We use professional and environmentally friendly packaging materials and customize the packaging according to the characteristics of the goods to ensure that the goods are safe and intact during transportation. At the same time, we have an efficient delivery process and a complete logistics system to ensure that you receive the goods as soon as possible.

Customer Feedback

Please feel free to leave us message if you have any question about us and our products.

Application Field

We mainly produce galvanized steel, color-coated steel, stainless steel, carbon steel, aluminum and other steel products. These steels have stable performance and reliable quality. They are suitable for engineering, coal mining, textiles, electricity, boilers, machinery and other industries, and can meet the actual needs of different customers. Friends from all walks of life are welcome to consult and cooperate!

COOPERATIVE PARTNER

FAQ

Q1: Are You Manufacture or Trade Company?

A1: We are the professional manufacturer of stainless/carbon/galvanized steel products located in China. Welcome to contact us and visit our factory before you place orders.

FAQ

Q2: Can I get free samples?

A2: Of course you can. We can produce according to your samples or technical drawings. Contact us by whatsapp or email to get free samples and you will get the sample after 3-7 working days.

FAQ

Q3: How do you guarantee the quality?

A3: We can send free samples to you, we can accept third-party testing. We also have test certificate, every batch goods will be testing before shipment, and the testing report will delivery to you with your goods.

FAQ

Q4:How many coutries you already exported ?

A4: Exported to more than 50 countries mainly from Qatar, America, Russia, Belarus, Saudi Arabia, United Arab Emirates, Kuwait, Brazil, Egypt, Turkey, Jordan, India, etc.

FAQ

Q5:How long is your delivery time?

A5:Within 5 days for stock size, 7-15 working days for customized size.

FAQ

Q6: Can you OEM or ODM?

A6: Yes, we have a strong developing team. The products can be made according to your request

FAQ

Q7: What is the MOQ?

A7: If you are scheduling to place a small quantity order or trial order, feel free to contact us, we can meet your requirements.

FAQ

Q8:What are the certifications for your products?

A8:We have ISO 9001, MTC, third parties' inspections are all available such SGS, BV ect.
